MILITARY STRINGLIGHT

— INDUSTRIES

Expedition Tactical LED Shelter Lighting System

The World's Most Advanced Military Shelter Lighting System

TWICE AS BRIGHT, UNPRECEDENTED CONTROL, EMERGENCY MODE, COVERT / BLACK-OUT MODE, WORKS ANYWHERE, ANYTIME

Twice as bright as standard soft-walled shelter lights

  • Fewer lights per shelter mean reduced acquisition costs, reduced logistical costs, and shorter set-up / take down time

  • Lind's military string lights have advanced optical diffusion built right into the extra durable polycarbonate lens to provide uniform, glare-free light

Unprecedented central control

  • Conveniently control all of the light functions from modular control boxes (on, off, and covert mode shown here. 0-100% dimming also available)

  • Place an unlimited number of fully modular control boxes at any point in the shelter (e.g. entrances), and control all of the lights from any of those control boxes

  • Each fixture also retains local control or can be configured to work without the central control boxes

Advanced emergency mode for power-loss situations

  • Optional emergency mode functionality keeps the lights on at lower levels for up to 15 minutes upon power loss without the need for batteries

  • Expedition system intelligently differentiates between lights being turned off (emergency mode will NOT engage) and loss of power (emergency mode WILL engage)

  • Expedition Tactical LED Lighting System performs these functions without the use of batteries and requires no maintenance

Instant Covert / Black-out Mode

  • With a push of a button on any of the modular central control boxes, all of the military stringlights in the shelter will switch to covert / black-out mode

  • No need to put a physical color filter on the lights or turn each one individually into covert mode, saving time and eliminating errors in critical situations

  • A range of NVIS colours is available (Green A, Red, Blue). See the ordering guide below!

Works anywhere, any time, every time

  • Connects to 120V or 240V power for interoperability with allies

  • IP67 rated

  • Operates in -40°C/-40°F to +49°C/120°F

  • String up to 16 military stringlights together

  • LEDs rated for over 50,000 hours

  • EMI compliant to MIL-STD-461 (RE102, CE102, RS103 for Ground Equipment)

  • Field serviceable

Available for GSA Members

Unprecedented central control of your shelter lighting system

Current shelter lighting systems require controlling the light levels, covert/black-out modes and any other lighting functions at the individual fixtures.  This means that every light must be touched to move to a dimmer lighting environment, or a critical black-out environment, which wastes time and increases the chance of error.

WIth the Lind Equipment Expedition Tactical LED Shelter Lighting System, every light in the shelter can have all of its functions controlled centrally using our central control boxes.  These boxes are modular in nature and an unlimited number of them can be placed anywhere in the shelter.  This means a central control could be placed at every entrance to the shelter, providing the ultimate control over your shelter lighting situation.

Lind Equipment's Expedition lights also have a set of buttons that control the individual light's functions.  The central control will override these choices if a different mode is selected centrally.

1 - Every shelter using the central control requires one Central Control Box

  • Central Control box plugs into the 120V or 240V power source

2 - Expedition Lights are connected in series from the Central Control box

  • Lights are connected to Central Control and to each other using an IP67 multi-pin connector that passes electricity and control information through the entire shelter

3 - Add Auxiliary Control box at any point between lights

  • Auxiliary Control boxes use the same connectors and "T-junction" off the lights

4 - An unlimited number of Auxiliary Control boxes can be added

  • Auxiliary and Central Control boxes will control all the lights in the shelter

To take advantage of the central control functionality, make sure your Expedition Lighting System is ordered correctly

  • Configure the lights to use this advanced functionality by adding the central control option in the part number (add -CB to the part number for each light)

Want less control?

  • If you don't want central control functionality, then simply configure your Expedition light part numbers accordingly

  • Order your Expedition lights without the central control functionality by NOT including that option in the part number (i.e. do NOT include -CB)

  • No need to order any Central Control or Auxiliary Control boxes

  • Expedition lights will come with 5-15 plugs and receptacles for plugging into the power source and daisy-chaining together in series

Ordering the Expedition Tactical LED Shelter Lighting System

Be sure to order your Expedition Tactical LED Military Shelter Lighting System in a way that is configured to your needs.  Part number nomenclature for the individual light fixtures is below, and the accessories, including control boxes and carrying cases, are listed below.

The Expedition stringlights are incredibly versatile, and many different configurations can be made.  Here are some examples to assist you in creating the right part number:

LE7055-W    A basic light.  No central control only illuminates in white light.

LE7055-W-G-F   White light with NVIS Green A covert mode, EMI filtered.  There is no emergency mode and no central control functionality.

LE7055-W-R-EM-F   White light with NVIS Red covert mode, emergency mode, and EMI filtered.  No central control functionality.

Notes regarding central control:

  • All string lights in a single shelter must have the same choice as central control or not. i.e. they must all have "-CB" or all NOT have "-CB"

  • If "-CB" is selected, one Central Control box (LE7055-CC) must be purchased per shelter

  • If "-CB" is selected, an unlimited number of Auxiliary Control boxes (LE7055-AC) can be purchased

  • LE7055-CC and LE7055-AC will not work with lights that do not have the "-CB" function

If you have any questions, please do not hesitate to contact us.
